Built—in lithium battery
lntelligent circuit design with over charging, over-discharging and short circuit protection
DC 5v/9V/12v output voltage selectable
Customized products of various capacities
| Model | DC1018P | DC1036P |
| Input | 85-265Vac/50-60Hz | |
| Output | USB 5V/2A | USB 5V/2A |
| DC 5V/2A | DC 5V/2A | |
| DC 9V/1A | DC 9V/2A | |
| DC 12V/1A | DC 12V/2A | |
| POE 15V/0.6A | POE 15V/1A | |
| POE 24V/0.6A | POE 24V/1A | |
| Output power(Max.) | 18W | 36W |
| Quantity & Capacity of battery | 2200mAh*4(Lithium battery) | |
| Operate temperature | -10℃ - 40℃ | |
| Humidity | 10%-90%RH | |
| Dimension(mm) | 160*105*33mm | |
| Net weight(kg) | 0.41kg | 0.42kg |
Uninterruptible Power Supply Mini DC UPS 12V 9V with USB
UPS mini DC UPS 5V 9V 12V with lithium battery
